P3.91 Indoor SMD2121 8kg Aluminum Cabinet Rental Led Display For Stage
Description
1. Good viewing angle: there is a large viewing angle both horizontally and vertically, which is suitable for the environment with wide horizontal distribution and large height drop.
2. Good effect: using nonlinear point by point correction technology, the text is clearer and the sense of hierarchy is stronger;
3. Strong reliability: distributed scanning technology and modular design technology are adopted, with higher reliability and stability;
4. Diversified display modes: support multiple display modes;
5. Convenient operation: the edited content of the computer can be displayed when it is sent to the system control card. The system operation is very convenient.
1. High refresh rate and high gray depth.
2. Completely black LED with high contrast.
3. Standard cabinet size is 500mm x 500mm and 480x480mm.
4. Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.
5. Exactly connected and easy to install and dismount.
Technique Parameter:
| P3.91 Indoor&Outdoor LED Screen Technicial Parameters |
| Led Module Specification |
| NO. | Item | Specification |
| 1 | Pixel Pitch | 3.91mm |
| 2 | Module Resolution | W64×H64dots |
| 3 | Module Size | 250*250mm |
| 4 | Led Packing | 1921 ( Outdoor ) | 2121 (Indoor ) |
| 5 | IP Rate | IP65 ( Outdoor ) | IP43 (Indoor ) |
| 6 | IC | 2038s |
| 7 | LED composition | 1R1G1B |
| Cabinet Specification |
| 1 | Cabinet Size | 500*1000mm or 500*500mm |
| 2 | Module Qty | W2X H2 =4PCS |
| 3 | Physical Resolution | W128×H128dots |
| 4 | Power Consumption(MAX.) | 200 W/m² |
| 5 | Power Consumption(AVE.) | 120 W/m² ( Outdoor ) | 80 W/m² ( Indoor ) |
| 6 | Cabinet Material | Die-casting Aluminum |
| 7 | Physical Density | 65410 dots/m² |
8 |
Net Weight | 14.8Kg (500*1000mm) | 8Kg
(500*500mm ) |
| Screen Specification |
| 1 | Brightness | 4500cd/m² ( Outdoor) | 900cd/m² (Indoor) |
| 2 | Colors | 16.7 trillion |
| 3 | Brightness Control | Software 256 level adjustable |
| 4 | Gray Level | 14 |
| 5 | View Distance | 2～100m |
| 6 | Refresh Rate | ≥1200~1920Hz |
| 7 | Drive Mode | 1 / 32s |
| 8 | Life Span | 100,000h |
| 9 | MTBF | 1000h |
| 10 | Control mode | Synchronous control or Asynchronous control |
| 11 | Frame Frequency | ≥60Hz |
| 12 | Certification | CE/ROHS/FCC/CCC/ISO9001/ISO14001 |
| 13 | Operation Temperature | -20℃ ～ +45℃ |
| 14 | Operation Humidity | 10%～95% |
